Product Summary
The TMS320C6203BGNY300 is a fixed-point digital signal processor. The DSP device is based on the high-performance, advanced VelociTI very-long-instruction-word (VLIW) architecture developed by Texas Instruments (TI), making these DSPs an excellent choice for multichannel and multifunction applications. The TMS320C6203BGNY300 has a performance capability of up to 2400 MIPS at a clock rate of 300 MHz. It possesses the operational flexibility of high-speed controllers and the numerical capability of array processors. This processor has 32 general-purpose registers of 32-bit word length and eight highly independent functional units.
Parametrics
Absolute maximum ratings: (1)Supply voltage range, CVDD: -0.3 V to 1.8 V; (2)Supply voltage range, DVDD: -0.3 V to 4 V; (3)Input voltage range: -0.3 V to 4 V; (4)Output voltage range: -0.3 V to 4 V; (5)Operating case temperature ranges, TC: (default): 0℃ to 90℃; (6)Storage temperature range, Tstg: -65℃ to 150℃; (7)Temperature cycle range, (1000-cycle performance): -40℃ to 125℃.
Features
Features: (1)High-Performance Fixed-Point Digital Signal Processor (DSP) TMS320C62x: 4-, 3.33-ns Instruction Cycle Time; 250-, 300-MHz Clock Rate; Eight 32-Bit Instructions/Cycle; 2000, 2400 MIPS; (2)C6203B and C6202 GLS Ball Grid Array(BGA) Packages are Pin-Compatible With the C6204 GLW BGA Package; (3)C6203B and C6202B GNZ and GNY Packages are Pin-Compatible; (4)VelociTI Advanced Very-Long-Instruction-Word (VLIW) C62x DSP Core; (5)Four-Channel Bootloading Direct-Memory-Access (DMA) Controller With an Auxiliary Channel; (6)Flexible Phase-Locked-Loop (PLL) Clock Generator; (7)32-Bit Expansion Bus (XBus); (8)Two 32-Bit General-Purpose Timers; (9)IEEE-1149.1 (JTAG) Boundary-Scan-Compatible.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TMS320C6203BGNY300 |
Texas Instruments |
Digital Signal Processors & Controllers (DSP, DSC) Fixed-Pt Dig Signal Proc |
Data Sheet |
|
|
||||||||
